Μικροαυτόματος πίνακος 1X25A SH201T-C25 ABB
Κωδικός: C25A
4,00 €
με ΦΠΑ
Περιγραφή : | Μικροαυτόματος πίνακος 1X25A SH201T-C25 ABB |
Τεχνικά χαρακτηριστικά : | · L+N : ΟΧΙ · Αριθμός πόλων (σύνολο) : 1 · Αριθμός Προστατευόμενων πόλων : 1 · Αριθμός στοιχειων πλατ. 17,5mm : 1 · Βραχυκύκλωμα διακοπής EN 60898 : 3kA · Δυνατότητα πρόσθ. Εξοπλισμού : ΝΑΙ · Ονομαστική τάση : 230V · Ονομαστικό ρεύμα : 25A · Τύπος τάσης : AC · Χαρακτηριστικό απόζευξη : C |
Συμβατοί κωδικοί : | SH201T-B25 |
Technical
- Standards:
- IEC/EN 60898-1
- Number of Poles:
- 1
- Number of Protected Poles:
- 1
- Tripping Characteristic:
- B
- Rated Current (In):
- 16 A
- Rated Operational Voltage:
- acc. to IEC 60898-1 230 / 400 V AC
- Rated Voltage (Ur):
- 230 V AC
- Power Loss:
- 2.5 W
at Rated Operating Conditions per Pole 2.5 W
- Rated Insulation Voltage (Ui):
- acc. to IEC/EN 60664-1 440 V
- Operational Voltage:
- Maximum (Incl. Tolerance) 253 V AC
Minimum 12 V AC
- Rated Frequency (f):
- 50 / 60 Hz
- Rated Short-Circuit Capacity (Icn):
- (230 / 400 V AC) 3 kA
- Energy Limiting Class:
- 3
- Overvoltage Category:
- III
- Pollution Degree:
- 2
- Rated Impulse Withstand Voltage (Uimp):
- 4 kV
at 2000 m 5 kV
at Sea Level 6.2 kV
- Dielectric Test Voltage:
- 50/60 Hz, 1 min: 2 kV
- Housing Material:
- Insulation Group II, RAL 7035
- Actuator Type:
- Toggle
- Actuator Material:
- Insulation Group II, Black, Sealable
- Actuator Marking:
- I / O
- Contact Position Indication:
- ON / OFF
- Degree of Protection:
- IP20
- Electrical Endurance:
- 20000 AC cycle
- Mechanical Endurance (Nendu):
- 20000 cycle
- Terminal Type:
- Screw Terminals
- Screw Terminal Type:
- Cage Terminal
- Connecting Capacity:
- Conductor 25 / 25 mm²
Flexible with Ferrule 0.75 ... 16 mm²
Flexible 0.75 ... 16 mm²
Rigid 0.75 ... 25 mm²
Stranded 0.75 ... 25 mm²
- Tightening Torque:
- 2 N·m
- Recommended Screw Driver:
- Pozidriv 2
- Mounting on DIN Rail:
- TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
- Mounting Position:
- Any
- Built-In Depth (t2):
- 69 mm
- Installation Size:
- acc. to DIN 43880 1
- Power Supply Connection:
- Arbitrary
Environmental
- Ambient Air Temperature:
- Operation -25 ... +55 °C
Storage -40 ... +70 °C
- Reference Ambient Air Temperature:
- 30 °C
- Resistance to Shock acc. to IEC 60068-2-27:
- 25g / 2 shocks / 13 ms
- Resistance to Vibrations acc. to IEC 60068-2-6:
- 5g, 20 cycles at 5 ... 150 ... 5 Hz with load 0.8 In
- Environmental Conditions:
- 28 cycles
with 55 °C / 90-96 %
and 25 °C / 95-100 %
- RoHS Status:
- Following EU Directive 2011/65/EU
Dimensions
- Product Net Width:
- 17.5 mm
- Product Net Depth / Length:
- 69 mm
- Product Net Height:
- 85 mm
- Product Net Weight:
- 0.125 kg
Container Information
- Package Level 1 Units:
- carton 10 piece
- Package Level 1 Width:
- 92 mm
- Package Level 1 Depth / Length:
- 183 mm
- Package Level 1 Height:
- 80 mm
- Package Level 1 Gross Weight:
- 1.3 kg
- Package Level 2 Units:
- 120 piece
- Package Level 2 EAN:
- 4016779990165
Ordering
- Minimum Order Quantity:
- 1 piece
- Customs Tariff Number:
- 85362010
Certificates and Declarations (Document Number)
- Declaration of Conformity - CE:
- 9AKK107046A5460
- Environmental Information:
- 2CDK400030D0201
- Instructions and Manuals:
- Printed on packaging
- RoHS Information:
- 2CDK400030D0201
Popular Downloads
- Data Sheet, Technical Information:
- 2CSC400030D0202
- Instructions and Manuals:
- Printed on packaging
Classifications
- Object Classification Code:
- F
- ETIM 6:
- EC000042 - Miniature circuit breaker (MCB)
- ETIM 7:
- EC000042 - Miniature circuit breaker (MCB)
- ETIM 8:
- EC000042 - Miniature circuit breaker (MCB)
- eClass:
- V11.0 : 27141901
- UNSPSC:
- 39121614
